| 产品型号 | 中心频率(MHz) | 使用带宽 | 带宽(-3dB) | 插入损耗 | 阻抗 | 封装 | | F165M | 165 | 22 | 25.88 | 9.3 | 50Ω and matching network | 3.8*3.8-6 | | F247B | 247.45 | 0.22 | 0.49 | 2.2 | 50Ω and matching network | 3.8*3.8-6 | | F307A | 307.075 | 5.9 | 12.37 | 1.5 | 50Ω | 3.8*3.8-6 | | F308F | 308.5 | 16 | 18.9 | 3.2 | 150Ω | 3.8*3.8-6 | | F315A | 315 | 4 | | 2.8 | 50Ω | 3.8*3.8-6 | | F328F | 328 | 16 | 19.4 | 3.5 | 150Ω | 3.8*3.8-6 | | F340C | 340 | 8 | 15.2 | 2.65 | 50Ω | 3.8*3.8-6 | | F344AN | 344 | 3 | | 4 | 50Ω | 3.8*3.8-6 | | F344A | | 6 | 14.44 | 1.6 | 50Ω | 3.8*3.8-6 | | F354.5A | | 7 | 12.14 | 2.3 | 50Ω | 3.8*3.8-6 | | F364.5A | | 7 | 12.5 | 1.9 | 50Ω | 3.8*3.8-6 | | F369A | | 4 | 8.75 | 3 | 50Ω | 3.8*3.8-6 | | F374E | | | 22 | 9 | 50Ω | 3.8*3.8-6 | | F375.5C | | 11 | 15.3 | 1.8 | 50Ω | 3.8*3.8-6 | | F380C1 | | 10 | 15.6 | 1.8 | 50Ω | 3.8*3.8-6 | | F383A | | 6 | 13.4 | 2.5 | 50Ω | 3.8*3.8-6 | | F387A | | 6 | 13.44 | 2 | 50Ω | 3.8*3.8-6 | | F384C | 384 | 4 | 13 | 1.6 | 50Ω | 3.8*3.8-6 | | F390G | 390 | 20 | | 9 | 50Ω | 3.8*3.8-6 | | F393A | 393.5 | 5 | 12.93 | 3.2 | 50Ω | 3.8*3.8-6 | | F398A | 398 | 4 | 9.1 | 2.5 | 50Ω | 3.8*3.8-6 | | F403C | 403 | 8 | 16.7 | 2.5 | 50Ω | 3.8*3.8-6 | | F410A | 410 | 6 | 10.26 | 2.5 | 50Ω | 3.8*3.8-6 | | F418A | 418 | 4 | 10.7 | 3.2 | 50Ω | 3.8*3.8-6 | | F422A | 422 | 6 | 10.6 | 3 | 50Ω | 3.8*3.8-6 | | F426A | 426 | 6 | 10.6 | 2.8 | 50Ω | 3.8*3.8-6 | | F428W | 428 | 12 | 17.46 | 1.8 | 50Ω | 3.8*3.8-6 | | F430A | 430 | 7 | 10.7 | 2 | 50Ω | 3.8*3.8-6 | | F433C | 433 | 10 | 14.67 | 2.68 | 50Ω | 3.8*3.8-6 | | F433M | 433.92 | | 0.6 | 3 | 50Ω and matching network | 3.8*3.8-6 | | F434A | 433.92 | 6 | 11.88 | 2.5 | 50Ω | 3.8*3.8-6 | | F434B | 434 | 6 | 8.96 | 2.2 | 150Ω | 3.8*3.8-6 | | F440A | 440 | 4 | 15.7 | 2.3 | 50Ω | 3.8*3.8-6 | | F446A | 446 | 4 | 10.9 | 3.2 | 50Ω | 3.8*3.8-6 | | F446B | 446 | 6 | 10.6 | 2 | 150Ω | 3.8*3.8-6 | | F454A | 454 | 4 | 12 | 3 | 50Ω | 3.8*3.8-6 | | F455A1 | 455 | 10 | 13.5 | 2.2 | 50Ω | 3.8*3.8-6 | | F458A | 458 | 6 | 11.1 | 3.2 | 50Ω | 3.8*3.8-6 | | F458C | 458 | 10 | 17 | 3.2 | 50Ω | 3.8*3.8-6 | | F460E | 460 | 20 | 27.7 | 2.6 | 50Ω | 3.8*3.8-6 | | F465A | 465 | 6 | 11.6 | 3 | 50Ω | 3.8*3.8-6 | | F465A1 | 465 | 10 | 18.8 | 2.5 | 50Ω | 3.8*3.8-6 | | F465B | 465 | 6 | 9.4 | 2.2 | 150Ω | 3.8*3.8-6 | | F465C | 465 | 10 | 18.4 | 3.3 | 50 | 3.8*3.8-6 | | F467A | 467 | 6 | 11.8 | 2.2 | 50Ω | 3.8*3.8-6 | | F470A | 470 | 6 | | 3 | 50Ω | 3.8*3.8-6 | | F474B | 474 | 6 | | 2 | 150Ω | 3.8*3.8-6 | | F475C | 475 | 10 | | 2 | 50Ω | 3.8*3.8-6 | | F477A | 477 | 6 | 11.5 | 3 | 50Ω | 3.8*3.8-6 | | F477C | 477 | 8 | 20.9 | 2.8 | 50Ω | 3.8*3.8-6 | | F480-1 | 480 | 2 | 17.2 | 18.7 | 50Ω | 3.8*3.8-6 | | F480A | 480 | 6 | 12.3 | 3 | 50Ω | 3.8*3.8-6 | | F480C | 480 | 6 | 19.6 | 3.2 | 50Ω | 3.8*3.8-6 | | F482A1 | 482 | 8 | 19.2 | 1.8 | 50Ω | 3.8*3.8-6 | | F485C | 485 | 10 | 18.8 | 2 | 50Ω | 3.8*3.8-6 | | F498A | 498 | 5 | 19.8 | 2 | 50Ω | 3.8*3.8-6 | | F546A | 546 | 8 | 21.7 | 1.8 | 50Ω | 3.8*3.8-6 | | F618A | 618 | 8 | 22.8 | 2.2 | 50Ω | 3.8*3.8-6 | | F626A | 626 | 8 | 24 | 1.8 | 50Ω | 3.8*3.8-6 | | F666A | 666 | 8 | 25.2 | 2 | 50Ω | 3.8*3.8-6 | | F674A | 674 | 8 | 25.1 | 2 | 50Ω | 3.8*3.8-6 | | F682A | 682 | 8 | 25.6 | 1.8 | 50Ω | 3.8*3.8-6 | | F707C | 707 | 18 | 26.7 | 4.1 | 50Ω | 3.8*3.8-6 | | F714A | 714 | 18 | 27 | 2.2 | 50Ω | 3.8*3.8-6 | | F722A | 722 | 18 | 25.5 | 1.8 | 50Ω | 3.8*3.8-6 | | F736C | 736 | 12 | 30 | 3.5 | 50Ω | 3.8*3.8-6 | | F738A | 738 | 8 | 27.3 | 1.8 | 50Ω | 3.8*3.8-6 | | F744E | 744.5 | 8 | 26.6 | 3.1 | 50Ω | 3.8*3.8-6 | | F746A | 746 | 8 | 18 | 2.6 | 50Ω | 3.8*3.8-6 | | F746A2 | 746 | 8 | 27.5 | 2.3 | 50Ω | 3.8*3.8-6 | | F754A | 754 | 8 | 27.9 | 2 | 50Ω | 3.8*3.8-6 | | F760E | 760.5 | 19 | 26.1 | 1.5 | 50Ω | 3.8*3.8-6 | | F764A | 764.2375 | 8 | 14 | 2.5 | 50Ω | 3.8*3.8-6 | | F765E | 765.5 | 20 | 28.8 | 3.3 | 50Ω | 3.8*3.8-6 | | F770C | 770 | 12 | 33.4 | 3.3 | 50Ω | 3.8*3.8-6 | | F770A | 770 | 8 | 28.4 | 2.5 | 50Ω | 3.8*3.8-6 | | F775E | 775.5 | 18 | | 2.5 | 50Ω | 3.8*3.8-6 | | F778A | 778 | 8 | 28.2 | 2.5 | 50Ω | 3.8*3.8-6 | | F782C | 782 | 12 | 28.1 | 2.2 | 50Ω | 3.8*3.8-6 | | F786A | 786 | 8 | 28.9 | 1.6 | 50Ω | 3.8*3.8-6 | | F794A | 794 | 8 | 28.3 | 2.1 | 50Ω | 3.8*3.8-6 | | F798AT | 798 | 22 | | 3 | 50Ω | 3.8*3.8-6 | | F802A1 | 802 | 8 | 28.9 | 2.1 | 50Ω | 3.8*3.8-6 | | F812E | 812 | 18 | 30 | 1.7 | 50Ω | 3.8*3.8-6 | | F826E | 826.75 | 19 | 29.5 | 2.5 | 50Ω | 3.8*3.8-6 | | F841E | 841.25 | 19 | 29.3 | 2.5 | 50Ω | 3.8*3.8-6 | | F860E | 860 | 30 | 40.7 | 2.5 | 50Ω | 3.8*3.8-6 | | F865C | 865 | 10 | 19.1 | 3.5 | 50Ω | 3.8*3.8-6 | | F868.3A1 | 868.3 | 7 | 13.8 | 3.1 | 50Ω | 3.8*3.8-6 | | F870A | 869.85 | 4 | 13.1 | 3.8 | 50Ω | 3.8*3.8-6 | | F921A2 | 921 | 6 | 14.5 | 3.2 | 50Ω | 3.8*3.8-6 | | F930A | 930 | 4 | 16.3 | 2.5 | 50Ω | 3.8*3.8-6 | | F931A | 931 | 4 | 16.4 | 2.5 | 50Ω | 3.8*3.8-6 | | F959A | 959 | 2 | 15 | 2.8 | 50Ω | 3.8*3.8-6 | | F972C | 972 | 20 | 41 | 3.5 | 50Ω | 3.8*3.8-6 | | F385.5C | 385.5 | 11 | 15.9 | 1.8 | 50 | 3.8*3.8-6 | | F408C | 408 | 10 | 13.8 | 2.8 | 50 | 3.8*3.8-6 | | F412A1 | 412 | 2 | 9.8 | 2 | 50 | 3.8*3.8-6 | | F425A1 | 425 | 422-424 | 9.6 | 2.2 | 50 | 3.8*3.8-6 | | F450C1 | 450 | 4 | 17 | 1.8 | 50 | 3.8*3.8-6 | | F472.5A | 472.5 | 6 | | 3 | 50 | 3.8*3.8-6 | | F591E | 591 | 30 | | 3.8 | 50 | 3.8*3.8-6 | | F621E | 621 | 30 | | 4 | 50 | 3.8*3.8-6 | | F622M1 | 622.08 | | 0.77 | 3.66 | 50 and matching network | 3.8*3.8-6 | | F652E | 652 | 32 | | 4.5 | 50 | 3.8*3.8-6 | | F683E | 683 | 30 | | 3.5 | 50 | 3.8*3.8-6 | | F650A3 | 650 | 4 | 12.7 | 2.5 | 50Ω | 3.8*3.8-6 | | F670A3 | 670 | 4 | 13.3 | 2 | 50Ω | 3.8*3.8-6 | | F696A3 | 696 | 4 | 13.8 | 2.2 | 50Ω | 3.8*3.8-6 |
|
